德国wika 232.50.160通用不锈钢压力表NS160

功能特性
*的负载循环稳定性和抗冲击性能
不锈钢结构
德国劳氏认证和高斯特认证
量程：高达0 … 160 MPa
可以连接隔膜密封件
Description
These limit indicators find their application wherever
overpressures must be displayed with certainty and not be
tampered with, such as in the process, chemical or petrochemical
industries, in power plants, in the environmental sector,
in machine building or in general plant construction.
The limit indicator is a mechanical indicator mounted on the
dial with two settings.
The indicator is slid from the actual value pointer via a drive
pin from a green area to a red area, when the set limit value
is exceeded. In the red area, the indicator is locked and is
unable to move back from there.
If the indicator is in the green area, the pressure limit being
monitored has not been exceeded.
Special
If the indicator is found in the red area, the set pressure range
has been exceeded at least once.
In this case, the indicator will remain permanently locked
and protected from tampering in the red area.
To prevent tampering with the limit indicator, the pressure
measuring instruments can be optionally lead sealed, or
be offered with an adhesive seal that cannot be peeled off
without destroying it.
Example:
If the pressure rises to approx. 10 % above the set value,
which is 8 bar in this example (as shown in the photo), an
indicator is locked into a predefined channel by the instrument
pointer. The indicator cannot be reset anymore.
应用
带可充液外壳，可用于具有高动态压力脉冲或振动的应用场合
适用于非高粘度或不易结晶的侵蚀性气体和液体介质以及侵蚀性环境
过程工业：化工、石化、发电站、采矿、沿海和离岸平台、*技术、机械制造和设备建造
